Cracking Mills

• Equipment Output (T/24H): 400-450（soybean）
• Roll Size (mm): 400 * 1500
• Weight (≈t): 7.5
• Main Motor Power: 22kW, 2 pieces

• Equipment Output (T/24H): 350-400（soybean）
• Roll Size (mm): 400 * 1250
• Weight (≈t): 6.5
• Main Motor Power: 18.5kW, 2 pieces

• Equipment Output (T/24H): 300-350（soybean）
• Roll Size (mm): 400 * 1000
• Weight (≈t): 5
• Main Motor Power: 15kW, 2 pieces

• Equipment Output (T/24H): 1000（soybean）
• Roll Size (mm): 305 * 1830
• Weight (≈t): 7.3
• Main Motor Power: 75kW, 1 pieces

• Equipment Output (T/24H): 300-350（soybean）
• Roll Size (mm): 300 * 1250
• Weight (≈t): 3.8
• Main Motor Power: 18.5kW, 2 pieces

• Equipment Output (T/24H): 200-250（soybean）
• Roll Size (mm): 300 * 1000
• Weight (≈t): 3.4
• Main Motor Power: 15kW, 2 pieces

• Equipment Output (T/24H): 180-250（soybean）
• Roll Size (mm): 250 * 1250
• Weight (≈t): 3.5
• Main Motor Power: 15kW, 2 pieces

• Equipment Output (T/24H): 150-200(soybean)
• Roll Size (mm): 250 * 1000
• Weight (≈t): 3
• Main Motor Power: 11kW, 2 pieces

• Equipment Output (T/24H): 80-100(soybean)
• Roll Size (mm): 250 * 800
• Weight (≈t): 2.2
• Main Motor Power: 11kW, 2 pieces

• Equipment Output (T/24H): 30-60（soybean）
• Roll Size (mm): 250 * 600
• Weight (≈t): 1.8
• Main Motor Power: 7.5kW, 2 pieces

1. Main crushing machine body (frame, rolls, housings, end baffles)
2. Main motor, belts and motor base
3. Motor protection cover
4. Feeding reducer motor assembly
5. Basic electrical control components

Equipment Output (T/24H): 1300 – 1500 (soybean)

Approx. Output (kg/h): 54,170 – 62,500

Roll Size (mm): 400 × 2100

Alloy (Hard) Layer Thickness (mm): 20 – 25

Roll Hardness (HS): 69 ± 3

Crushing Size (inch): 1/4" – 1/8" Adjustable

Crushing Size (mm approx.): 6.3 – 3.2 Adjustable

Roll Speed (rpm): Fast 744 / Slow 494

Total Power (kW): 91.10

Weight (≈t): 13

Overall Dimensions (mm): 3400 × 1500 × 2150

Main Motor Power: 90 kW (Single)

Main Motor Brand: Innomotics (Beide) Brand

Feeding Reducer Power: 1.1 kW

Feeding Reducer Brand: Guomao

Bearing Brand: Domestic Chinese Brand

Voltage / Frequency: 380 V / 50 Hz

Control Voltage: DC 24 V (if control circuit configured)

Controlled particle size of 1/4–1/8 across the series supports stable downstream flaking, conditioning, extraction efficiency, and more consistent oil yield.

Centrifugally cast Ni-Cr-Mo (high Ni-Cr-Mo on larger models) alloy rolls with uniform chill layer (20–25 mm; 25–30 mm on C4210) and hardness HS69 ±3. Dynamic balance testing reduces vibration, prolonging roll and bearing life.

Annealed 45# welded steel bases (plus aged cast-steel frames on large models) resist deformation. Fully enclosed housing with front/rear opening doors and dual observation/receiving ports speeds inspection and cleaning, shortening downtime.

Spring-tightened roll mechanism absorbs shocks while keeping pressure stable; worm–gear digital spacing adjustment (on advanced models) prevents roll collision. Ridge (pinnacle) baffle structure minimizes side leakage and material loss.

Suited for soy, peanut, corn germ, sunflower seed, cotton seed, rapeseed, etc. Optimized differential fast/slow roll speeds enhance shear and fissure formation, supporting stable 24/7 operation.

Long-life alloy rolls + low vibration + reduced spillage + standardized bearing types (with SKF and centralized lubrication, magnetic separation, and advanced feeding/baffle systems on higher-end models) cut spare consumption, cleaning labor, unscheduled downtime, and per-ton operating cost.
